Product Advantages
- Electromagnetic force sensor
- Super bright detachable displayer
- Multi-unit weighing function, customizable units
- RS232 and USB bidirectional interface
- Glass windshield-antistatic material
- Fast sensitivity setting
- Below weighing system
- Time display
- The weighing results can be exported to Excel
- Built-in auto calibration system (Internal calibration model)
- Built-in stand-alone dual program (0.1mg)
Technical Specifications
| EX-Cal Model | CEB124 | CEB224 | CEB324 | CEB424 | CEB524 |
|---|---|---|---|---|---|
| Capacity | 0-120g | 0-220g | 0-320g | 0-420g | 0-520g |
| Readability | 0.1 mg | ||||
| Stable Time | 1.5 s | 2 s | |||
| Preheating | 30-60 mins | ||||
| Weighing Units | g / oz / ct / mg | ||||
| Min Weight | 0.1 mg | ||||
| Repeatability | ±0.1 mg | ±0.2 mg | |||
| Linearity | ±0.2 mg | ±0.3 mg | |||
| Interface | RS232 / USB | ||||
| Pan Size | Φ90 mm | ||||
| Packing Size | Inner: 430x320x415 mm, Master: 490x380x485 mm | ||||
| N.W. | 6280 g | ||||
| Power | AC110V-240V | ||||
Weighing function
- Basic weighing
- Dynamic weighing
- Piece counting
- Percent weighing
- Density determination
- Σ weighing function
- Pipette calibration function
| IN-Cal Model | CEB124N | CEB224N | CEB324N | CEB424N | CEB524N |
|---|---|---|---|---|---|
| Capacity | 0-120g | 0-220g | 0-320g | 0-420g | 0-520g |
| Readability | 0.1 mg | ||||
| Stable Time | 1.5 s | 2 s | |||
| Preheating | 30-60 mins | ||||
| Weighing Units | g / oz / ct / mg | ||||
| Min Weight | 0.1 mg | ||||
| Repeatability | ±0.1 mg | ±0.2 mg | |||
| Linearity | ±0.2 mg | ±0.3 mg | |||
| Interface | RS232 / USB | ||||
| Pan Size | Φ90 mm | ||||
| Packing Size | Inner carton: 430x320x415 mm Master carton: 490x380x485 mm | ||||
| N.W. | 6280 g | ||||
| Power | AC110V-240V | ||||
